SPECIAL HOSE:SIZES -10 -12 -16
EXCEEDS:EN 856 4SH,SIZES -20 -24 -32
FOUR WIRE SPIRAL THIN COVER HOSE
Construction
1 – Synthetic rubber tube
2 – Four high tensile steel wire spirals
3 – Synthetic rubber cover Abrasion resistant Type,MSHA flame retardant approved
Application
High pressure hydraulic system for use with hydraulic oils,both mineral and biological,polyglycol base oils,water-oil emulsions and water
Temperature range
Hydraulic oils:-40°C to +121°C (-40°F to +250°F)occasional peaks up to +125°C (+257°F)
Polyglycol base oils,water-oil emulsions and water:up to +85°C (+185°F)
